Brielmaier Motormäher GmbH Motor mower Brielmaier | 1
BA Motor mower S250 (Version 2021/09) 11
Air filter housing
The air filter is located in the air filter housing. The air filter prevents dust
particles from entering the engine.
For cleaning instructions, see chapter
Cleaning the intake manifold and
engine oil cooler
[}82].
Oil mist separator
The oil mist separator collects the oil droplets captured when the
crankshaft is ventilated and returns the oil to the engine. The air
containing exhaust gases is mixed with the combustion air via the air filter
housing.
Toolbox
The toolbox (1) contains a tool bag (2) with a selection of the required
tools, the connection plug for charging the battery, the diagnostics
connector, the connections for the radio remote control and electrical
fuses.
Battery
The battery is located in the battery compartment below the toolbox.
