Loading the machine
Load the machine as follows:
2
1
a) Make sure that the battery disconnector is switched off and discon-
nected.
b) Attach ropes, straps, or multi-point suspension gear to the transport
lugs on the handlebar attachment (1) and to the transport lugs on the
rod trunnion (2).
c) Make sure that the machine is level and pay attention to the centre of
gravity if it is off-centre.
d) Load the machine.
3.4 Loading the machine using drive-on ramps
NOTE
Optional drive-on ramps for loading the machine may be obtained
from Brielmaier GmbH. When using these drive-on ramps, also take
note of the information on the separate supplementary sheet.
1
2
To load the machine using drive-on ramps:
a) Screw the locking parts (1) firmly onto the loading area.
b) Hook the drive-on ramps (2) into the base parts (1).
c) Drive the machine up the ramp.
d) Make sure that the spikes of the spiked roller are firmly secured in the
base parts (1).
e) Unhook drive-on ramps (2).
f) Secure the machine on the loading area with tension straps to prevent
it from slipping and tipping on its wheels.
g) Observe the warning in chapter Load securing [}36]
