1.2 Overview
1
2
3 4
5 6 7
8
9
10
11
12
13
14
15
1 Tyres 9 Control panel
2 Exhaust guard 10 Oil mist separator
3 Hydraulic block 11 Engine cooling intake
manifold
4 Radio antenna with receiver
(optional for radio remote
control)
12 Combustion engine
5 Battery compartment 13 Rod trunnion
6 Toolbox 14 Hydraulic oil cooler
7 Fuel tank 15 Hydraulic oil expansion tank
8 Steering bar
