Brielmaier Motormäher GmbH Operation with radio remote control (optional) | 6
BA Motor mower S250 (Version 2021/09) 71
Radio transmitter
Radio transmitter version 2010
1
9
3
2
8
6
7
4
Radio transmitter version 2015
1
5
9
2
3
8
6
7
4
Radio transmitter version 2019
1
1
5
9
2
3
8
4
7
10
11
1 Control lever (one or two
depending on the variant)
Axle A control lever: Function
depends on the attachment
Axis B control lever: Function
depends on the attachment
7 "ON/OFF" button
2 "Speed level -/G-" button 8 "Speed level +/G+" button
3 "Direction of travel/T" button:
no function
9 Emergency stop mushroom
button
4 "Attachment" switch 10 "X" push button: no function
5 Display 11 "Y" button: no function
6 "Transmitter status" lamp (red/
green)
