Fine adjustment for upper roller feed speed
If either the upper cloth or lower cloth slips out of alignment in the feed direction while gluing is in progress, you
can make fine adjustments to the upper roller feed speed to correct the mis-alignment between the upper cloth
and the lower cloth.
< If upper cloth moves faster >
Move the feed speed adjustment switch (1) to the down position.
The upper roller feed speed will become slower by the ratio which has
been set in memory switch No. 255.
The upper roller feed speed will become slower even if gluing
operation is still in progress.
Refer to ā3.5ā for details on the memory switch setting method.
