Confidential
5-98
5.1.78 Gear 17/20
(1) Remove the Gear 17.
Fig. 5-146
(2) Remove the Gear 20.
Fig. 5-147
Gear 17
Frame L
Hoo
k
Hoo
k
Gear 20
Frame L
