Brother DCP-8065DN

App. 9-1 Confidential
LOCATION OF THE FERRITE CORE
Refer to the following chart as well to know the necessary ferrite core depending on models.
CCD FFC LD FFC Pol
yg
on motor FFC
Main motor FFC
Rela
y
front FFC
