Brother DCP-8065DN - LT Solenoid ASSY

Confidential
5-138
5.2.11 LT Solenoid ASSY
(1) Remove the bind B M3x10 Taptite screw, and then remove the LT solenoid ASSY.
(2) Remove the Solenoid release spring P/R from the LT solenoid ASSY.
Fig. 5-223
LT frame L
Taptite, bind B M3x10
LT solenoid ASSY
Solenoid release spring P/R
