Brother DCP-8065DN

6-20 Confidential
WARNING
- DO NOT subject the fuser unit to strong physical shocks or vibrations.
- DO NOT touch the rollers and the electrodes to prevent damage to the fuser unit In the following
figures.
Fig. 6-33
CAUTION
To prevent the deformation of the pressure roller, the fuser unit spare parts is shipped with its
pressure roller at low nip pressure. Before installing the fuser unit, turn back the levers to the
normal position by following instructions below.
1) Put the fuser unit on a flat, horizontal surface. Pull up each of the blue tab (a) on the right side
and left side.
Fig. 6-34
2) Make sure that the black lever (b) is in the position in the illustration below.
Fig. 6-35
(a) (b)
(a)
(b)
