Brother DCP-8065DN Servise Manual

Confidential
9-24
(8) Fuser unit failure
Possible cause
Step
Check
Result
Remedy
1 Is the contact of connector
CN1 and CN2 on the relay
rear PCB good?
No Reconnect the connector.
Poor
thermistor
harness
contact
2 Is the contact of connector
CN3 on the main PCB
good?
No Reconnect the connector.
Yes Replace the fuser unit. Thermistor
assembling
failure
3 Is the thermistor installed
properly?
No Reinstall the thermistor
properly.
Halogen
heater lamp
failure
4 Remove the fuser unit and
measure the resistance of
the halogen heater lamp. Is
it open circuit?
Yes Replace the halogen heater
lamp.
Heater harness
connection
failure
5 Is the heater harness
connector connected to the
low-voltage power supply
PCB and fuser unit secure?
No Reconnect the connectors
securely.
NOTE:
• This problem will be cleared if leaving the machine power ON for ten minutes.
• If the heater is cooled down sufficiently, this problem may be cleared by turning on the machine
power switch while pressing the Go button. Be warned, however, that this operation will melt
the fuser unit if the heater is hot.
(9) Main PCB failure
Possible cause
Step
Check
Result
Remedy
Main PCB 1 Is it possible to print the
test page with the method
of 8.4.5 ‘Test Pattern 1’ in
chapter 8?
No Replace the main PCB.
Software bug 2 Does this problem appear
when printing specific data
or printing under a specific
environment?
Yes Inform the Brother office of the
used specific data, machine
condition and system
environment.
