Brother DCP-8065DN Service Manual

1-3 Confidential
8. Copy Keys 10. Fax and Telephone Keys
Duplex (For MFC-8860DN and MFC-8870DW)
You can choose Duplex to copy on both sides of
the paper.
Contrast/Quality
(For MFC-8860DN and MFC-8870DW)
Lets you change the quality or contrast for the next
copy.
Contrast (For MFC-8460N)
Lets you change the contrast for the next copy.
Quality (For MFC-8460N)
Lets you change the quality for the next copy.
Enlarge/Reduce
Reduces or enlarges copies.
Tray Select
Lets you change which tray will be used for the
next copy.
Sort
Sorts multiple copies using the ADF.
N in 1
You can choose N in 1 to copy 2 or 4 pages onto
one page.
Hook
Press before dialing if you want to make sure a fax
machine answers, and then press [Start] key.
Also, press this key after you pick up the handset
of an external telephone during the F/T ring (fast
double-rings).
Resolution
Sets the resolution when sending a fax.
Search/Speed Dial
Lets you look up numbers stored in the dialing
memory and LDAP server* (* MFC-8860DN and
MFC-8870DW).
You can search the stored number by
alphabetically.
It also lets you look up the stored number in Speed-
Dial numbers by pressing [Shift] key and [Speed-
Dial] key simultaneously and then the three digit
number.
Redial/Pause
Redials the last number called. It also inserts a
pause when programming quick dial numbers.
9. Mode Keys 11. Print Keys
Fax
Puts the machine in Fax mode.
Scan
Puts the machine in Scan mode.
(For details about scanning. See Software User’s
Guide on the CD-ROM.)
Copy
Puts the machine in Copy mode.
Secure
Prints data saved in memory when you enter your
four-digit password.
Job Cancel
Cancels a print job and clears the machine memory.

Brother DCP-8065DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	32 MB
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Mac OS X 10.2.4 or greater Windows XP
Standard interfaces	USB 2.0
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	660 W
