Confidential
5-116
(11) Lift up the rear of the Separation pad ASSY MP to the direction of the arrow 11a and pull up
the Separation pad ASSY MP to remove.
Fig. 5-181
(12) Remove the MP separation spring from the MP frame.
Fig. 5-182
Separation pad ASSY MP
MP frame
MP separation spring
MP frame
11b
11a
