Brother DCP-8065DN

6-25 Confidential
(16) Put the Panel cover ASSY onto the machine body.
Fig. 6-44
(17) Secure the Document scanner with the two bind B M4x12 Taptite screws.
Fig. 6-45
Panel cover ASSY
Hooks
Document scanner
Taptite, bind B M4x12
Taptite, bind B M4x12
