Confidential
9-32
(I-4) All black
User Check
(1) Clean the corona wire of the drum unit.
(2) The drum unit may be damaged. Install a new drum unit.
Possible cause
Step
Check
Result
Remedy
Ground
contacts
1 Is the corona wire dirty? Yes Clean the corona wire
with the wire cleaner.
(2)
2 Is the corona wire broken? Yes Replace the drum unit.
Corona failure
3 Are the charge electrodes
between the machine body
and the drum unit dirty?
Yes Clean both electrodes.
(3)
Harness
connection
4 Is the laser unit connected
to the main PCB correctly?
No Connect the harness
between the laser unit
and the main PCB
correctly.
High-voltage
power supply
PCB failure
5 Is the problem solved after
replacing the high-voltage
power supply PCB?
Yes Replace the high-
voltage power supply
PCB.
Main PCB
failure
6 Is the problem solved after
replacing the main PCB?
Yes Replace the main PCB.
Laser unit
failure
7 Is the problem solved after
replacing the laser unit?
Yes Replace the laser unit.
To Next Page
