Brother MFC-8480DN Service Manual

App. 1-1
Confidential
FIRMWARE SWITCHES (WSW)
This appendix describes the functions of the Worker switches, which can be divided into two
groups: one is for customizing preferences designed for the shipping destination (Refer to
"4.18 EEPROM Customizing (Function code 74)" in Chapter 7) and the other is for modifying
preferences that match the machine to the environmental conditions. Use the latter group if
the machine malfunctions due to mismatching.
Each switch has eight selectors. However, some of them cannot be set by an end user. Only
selectors in the worker switch setting tables of this Appendix that are shaded can be set by
an end user.
The worker switch setting procedure is described in "4.6.1 Firmware switch setting (Function
code 10)" in Chapter 7.
■ Worker Switch
WSW No. Function Refer to:
WSW01 Dial pulse setting App. 1-4
WSW02 Tone signal setting App. 1-6
WSW03 PABX mode setting App. 1-7
WSW04 Transfer facility setting App. 1-9
WSW05 1st dial tone and busy tone detection App. 1-10
WSW06 [Redial/Pause] button setting and 2nd dial tone detection App. 1-11
WSW07 Dial tone setting 1 App. 1-13
WSW08 Dial tone setting 2 App. 1-14
WSW09 Protocol definition 1 App. 1-15
WSW10 Protocol definition 2 App. 1-16
WSW11 Busy tone setting App. 1-17
WSW12 Signal detection condition setting App. 1-18
WSW13 Modem setting App. 1-19
WSW14 AUTO ANS facility setting App. 1-20
WSW15 Redial facility setting App. 1-21
WSW16 Function setting 1 App. 1-22
WSW17 Function setting 2 App. 1-22
WSW18 Function setting 3 App. 1-23
WSW19 Transmission speed setting App. 1-24
WSW20 Overseas communications mode setting App. 1-25
WSW21 TAD setting 1 App. 1-26
WSW22 ECM and call waiting caller ID App. 1-26
WSW23 Communications setting App. 1-27
WSW24 TAD setting 2 App. 1-28
WSW25 TAD setting 3 App. 1-28
WSW26 Function setting 4 App. 1-29
WSW27 Function setting 5 App. 1-30
WSW28 Function setting 6 App. 1-31
WSW29 Function setting 7 App. 1-32

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
