Brother MFC-8480DN Service Manual

App. 1-58
Confidential
<WSW62> (Scanning light intensity to judge to be stable 2)
• Selectors 1 through 4:Change rate of the Scanner light intensity for scanning pages
compensation
The light intensity of the Scanner unit may be changed (decreased, especially), and
difference of density may appear among the scanning pages if continuous copying or
scanning is implemented from the ADF for a long time. To prevent the above, in simplex
copying or scanning from the ADF, the machine checks the change rate of the light intensity
in every page. Then, it takes the compensation data again if the rate is over the set value.
These selectors set the change rate of the light intensity to control such operations.
Change rate for simple compensation:
Change rate when compensating the pages using the standard data in the machine
memory without moving the Scanner unit to the designated position for scanning of the
compensation data.
Change rate for regular compensation:
Change rate when compensating the pages with moving the Scanner unit to the
designated position for scanning of the compensation data and obtaining the data actually.
For duplex scanning, this setting is not used since the machine takes the compensation
data of every page again.
Selector No. Function Setting and Specifications
1
I
4
Change rate of the Scanner
light intensity for scanning
pages compensation
Change rate Change rate
No.1234 for simple for regular
compensation compensation
0000: 3% 10% *
0001: 3% 7%
0010: 3% 15%
0011: 3% 20%
0100: 3% 25%
0101: 5% 10%
0110: 5% 15%
0111: 5% 20%
1000: 5% 25%
1001: 7% 15%
1010: 7% 20%
1011: 7% 25%
1100: 10% 15%
1101: 10% 20%
1110: 10% 25%
1111: 15% 30%
* Default
5
6
Selection of judging function
for simple scanning pages
compensation
No. 5 6
00:
Judges according to the change rate
0 1: Not judges
1 0: Judges every page
7
8
Selection of judging function
for regular scanning pages
compensation
No. 7 8
00:
Judges according to the change rate
0 1: Not judges
1 0: Judges every page
