Brother MFC-8480DN Service Manual

App. 1-59
Confidential
• Selectors 5 and 6 / 7 and 8:Selection of judging function for scanning pages
compensation
These selectors set the condition to control scanning pages compensation. Some
operation losses occur in the control of the compensation. If you want to start scanning
immediately even if the image quality is not good, set to "01: Not discriminates". If you want
to give priority to the image quality even though losses are increased, select one of others
("00: Discriminates depending on the rate of change" or "10: Discriminates every page").
<WSW63> (Function setting 25)
• Selector 3: Clock type
Setting this selector to "1"displays Japanese clock type (YMD). If this selector sets to "0",
select USA type (MDY) or European type (DMY) by WSW17 selector 5.
• Selector 4: Demo print type (Demo language)
This selector specifies the language for Demo print.
• Selector 8: Font support for Israel
To enable the font support for Israel, set this selector to "1".
Selector No. Function Setting and Specifications
1
2
Not used
3 Clock type
0 : Follow to WSW17
1 : Japanese Type (YMD)
4
I
7
Demo print type
(Demo language)
0000 : Other
0001 : English
0010 : USA
0011 : CANADA
0100 : JAPANESE
0101 : EU1
0110 : EU2
0111 : EU3
1000 : EU4
1001-1111 : Reserved
8 Font support for Israel 0: Disable 1: Enable

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
