Brother MFC-9560CDW Service Manual

Confidential
TRADEMARKS
The Brother logo is a registered trademark of Brother Industries, Ltd.
Apple and Macintosh are trademarks of Apple Inc., registered in the United States and other countries.
PCL is either a trademark or a registered trademark of Hewlett-Packard Company in the United States
and other countries.
Windows Vista is either a registered trademark or a trademark of Microsoft Corporation in the United
States and/or other countries.
Microsoft, Windows, Windows Server and Internet Explorer are registered trademarks of Microsoft
Corporation in the United States and/or other countries.
Linux is a registered trademark of Linus Torvalds in the United States and other countries.
PostScript and PostScript3 are either registered trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other countries.
ENERGY STAR is a U.S. registered mark.
Citrix and MetaFrame are registered trademarks of Citrix Systems, Inc. in the United States.
Intel, Intel Xeon and Pentium are trademarks or registered trademarks of Intel Corporation.
AMD, AMD Athlon, AMD Opteron and combinations thereof, are trademarks of Advanced Micro
Devices, Inc.
PictBridge is a trademark.
Each company whose software title is mentioned in this manual has a Software License Agreement
specific to its proprietary programs.
All other trademarks are the property of their respective owners.
The function comparative table for models as described in this Service manual are shown blow.
© Copyright Brother 2010
All rights reserved.
No part of this publication may be reproduced in any form or by
any means without permission in writing from the publisher.
All other product and company names mentioned in this manual
are trademarks or registered trademarks of their respective
holders.
Specifications are subject to change without notice.
Model
DCP-
9055CDN
DCP-
9270CDN
MFC-
9460CDN
MFC-
9465CDN
MFC-
9560CDW
MFC-
9970CDW
Duplex
Scanning
--- √ --- √√√
LAN Wired Wired Wired Wired Wired/
Wireless
Wired/
Wireless
Touch
Panel
--- √ --- --- --- √
Scanning
Size
A4 Legal A4 A4 A4 Legal
USB host --- √√√√√

Brother MFC-9560CDW Specifications

General

Type	all in one
Color	black
Touch Screen	no
Display Size	0 inches
Tray Capacity	300
Automatic Document Feeder Capacity	25 sheets
Paper Size	letter, legal, executive, folio, a4, a5, b6
Paper Handling	up to 300 sheets
Printing Method	color
Color Print Speed	25 pages per minute
Mono Print Speed	25 pages per minute
Print Resolution Mono	up to 2400 x 600
Print Resolution Color	up to 2400 x 600
Two-Sided Printing	no
Maximum Number of Pages Per Month	up to 40, 000
Reduction and Enlargement	yes
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Max Copies	99
Copier Resolution Mono	up to 2400 x 600
Copier Resolution Color	up to 2400 x 600
Cartridges	n/a
Number Of Cartridges	4
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	usb 2.0
OS Compatibility	none
Mobile Devices Connection	no

Weight and Dimensions

Height	16.1 inches
Width	19.8 inches
Net Weight	58.4 pounds
