BRP SUMMIT - Page 473

Section12TECHNICALDATA
Subsection 02 (LIQUID COOLED MODELS)
GSX/GTX/MX Z GSX/GTX/MX Z/SUMMIT
MODEL
500 SS 600 HO 800 HO
DRIVE
Typ e HPV VSA
Spring preload 0
GSX 44° 47°/44° 50°/40°
GTX 44° 47°/44° 47°/40°
MX Z (Adrenaline) 44° 47°/44° 50°/40°
MX Z (Ren./Ren. X) — 44° 47°/40°
MX Z (Trail) 44° 47°/44° —
SUMMIT (Adr.) — 47°/44° 44°
SUMMIT (Adr. 144”) — 47°/44°
SUMMIT (EUR) — 44°
SUMMIT (X) — — 44°
Driven pulley type
Cam angle
SUMMIT (X 144”) — — 47°/44°
Pulley distance Zmm(in)19.0 (.748) 20.0 (.787)
Xmm(in)37.0 ± 0.5 (1.457 ± 0.2)
Offset
Y – Xmm(in) 0.82 (.0032)
Drivebeltpartnumber P/N 417 300 197 417 300 166
Width (10) mm (in) 37.3 (1.327) 37.7 (1.484)
Drive belt
Wear limit mm (in) 34.9 (1.374) 35.3 (1.390)
Deflection mm (in) 32 ± 5 (1.260 ± .197)
Drive belt adjustment
Force (8) kg (lbf) 11.30 (24.91)
GSX/GTX 381 mm (15 in)
MX Z (Adrenaline) 381 mm (15 in)
MX Z (Ren./Ren. X) — 406 mm (16 in)
MX Z (Trail) 381 mm (15 in) —
Track (width)
SUMMIT — 406 mm (16 in)
GSX 3074 mm (121 in)
GTX 3456 mm (136 in)
MX Z (Adrenaline) 3074 mm (121 in)
MX Z (Ren./Ren. X) — 3456 mm (136 in)
MX Z (Trail) 3074 mm (121 in) —
— 3648 mm (144 in)
SUMMIT (Adr.)
— — 3840 mm (151 in)
— — 3648 mm (144 in)
— — 3840 mm (151 in)
Track (length)
SUMMIT (X)
— — 4038 mm (159 in)
