BRP SUMMIT - Page 474

Section 12 TECHNICAL DATA
Subsection 02 (LIQUID COOLED MODELS)
GSX/GTX/MX Z GSX/GTX/MX Z/SUMMIT
MODEL
500 SS 600 HO 800 HO
DRIVE
GSX 25.4 mm (1.0 in)
GTX 22.3 mm (.878 in)
GTX (EUR) 31.8 mm (1.25 in) — 31.8 mm (1.25 in)
25.4 mm (1.0 in)
MX Z (Adrenaline)
31.8 mm (1.25 in)
— 31.8 mm (1.25 in)
MX Z (Ren./Ren. X)
— — 44.5 mm (1.75 in)
MX Z (Trail) 25.4 mm (1.0 in) 25.4 mm (1.0 in) —
MX Z (Trail EUR) 31.8 mm (1.25 in) 31.8 mm (1.25 in) —
SUMMIT (Adr.) — 50.8 mm (2.0 in)
— — 50.8 mm (2.0 in)
Track (profile height)
SUMMIT (X)
— — 57.2 mm (2.25 in)
Adjustment Deflection mm (in) 30 to 35 (1.181 to 1.378)
Track adjustment
Force (9) kg (lbf) 7.3 (16)
GSX SC 3 121 in
GTX SC 3 136 in
MX Z (Adrenaline) SC 3 121 in
MX Z (Ren./Ren. X) — SC 3 136 in
MX Z (Trail) SC 3 121 in —
— SC 144 in
SUMMIT (Adr.)
— — SC 151 in
— — SC 144 in
— — SC 151 in
Track
SUMMIT (X)
— — SC 159 in
Suspension type
Ski R.A.S. A-arm
BRAKE
Brake fluid reservoir mL (U.S. oz) 60 (2.0)
GTLMA (DOT 4) (P/N 293 600 062)
Brake fluid (P/N)
Racing brake fluid SRF (DOT 4) (P/N 293 600 063)
mmr2005-101 475
