Section12TECHNICALDATA
Subsection 03 (LIQUID COOLED (SDI) MODELS)
GSX/GTX/MX Z
MODEL
600 HO SDI
FUEL SYSTEM
Throttle body type Dell'Orto
Idle speed ± 200 RPM 1600
Gas type Unleaded
Inside North America (R+M)/2 87 or higher
Pump octane number
Outside North America RON 91 or higher
Gas/oil ratio Injection
Injection oil XP-S 2-stroke synthetic blend
COOLING SYSTEM
Type Liquid
Ethyl glycol/water mix (50% coolant,
50% distilled water).
Mixture
Use coolant specifically designed for
aluminum engines.
Coolant
Premix P/N 219 700 362 — 12 x 1 L
Thermostat opening temperature °C(°F) 42 (108)
Radiator cap opening pressure kPa (PSI) 90 (13)
DRIVE
Chaincase oil XP-S Synthetic chaincase oil
GTX 21/43
GSX/MX Z 22/43
Adrenaline/Renegade/X 22/43
Renegade (EUR) 21/43
Renegade X (1.25 in track) 21/43
Chain drive ratio
MX Z
Renegade X (1.75 in track) 19/43
Pitch in 3/8
GSX Silent 74/13
GTX Silent 74/13
MX Z (Adrenaline/Renegade/X) Silent 74/13
MX Z (Renegade X, 1.25 in track) Silent 74/13
Chain
Type/links qty/plate qty
MX Z (Renegade X, 1.75 in track) Silent 72/13
Drive pulley type TRA III
Clutch engagement ± 100 RPM 3800
Spring color Blue/Yellow
Spring length 115.1 mm (4.531 in)
Weight —
Block —
Cap —
Pin (with roller (P/N 417 003 900)) Solid (P/N 417 004 308)
Ramp 410
Drive pulley calibration
Screw position 4
480 mmr2005-101
