Section 12 TECHNICAL DATA
Subsection 03 (LIQUID COOLED (SDI) MODELS)
GSX/GTX/MX Z
MODEL
600 HO SDI
DRIVE
Type HPV VSA
Spring preload 0
GSX/GTX/MX Z (Adrenaline/X) 47°/44°
Driven pulley type
Cam angle
MX Z (Renegade/Renegade X) 44°
Pulley distance Zmm(in)20.0 (.787)
Xmm(in)37.0 ± 0.5 (1.457 ± 0.2)
Offset
Y – Xmm(in)0.82 (.0032)
Drive belt part number P/N 417 300 197
Width (10) mm (in) 37.3 (1.327)
Drive belt
Wear limit mm (in) 34.9 (1.374)
Deflection mm (in) 32 ± 5 (1.260 ± .197)
Drive belt adjustment
Force (8) kg (lbf) 11.30 (24.91)
GSX/GTX/MX Z (Adrenaline/X) 381 mm (15 in)
Track (with)
MX Z (Renegade/Renegade X) 406.4 mm (16 in)
GSX/MX Z (Adrenaline/X) 3074 mm (121 in)
GTX 3456 mm (136 in)Track (length)
MX Z (Renegade/Renegade X) 3456 mm (136 in)
GSX 25.4 mm (1.0 in)
GTX 22.3 mm (.878 in)
GTX (EUR) 31.8 mm (1.25 in)
25.4 mm (1.0 in)
MX Z (Adrenaline/X)
31.8 mm (1.25 in)
MX Z (Renegade) 31.8 mm (1.25 in)
MX Z (Renegade X, 1.25 in track) 31.8 mm (1.25 in)
Track (profile height)
MX Z (Renegade X, 1.75 in track) 44.5 mm (1.75 in)
Adjustment deflection mm (in) 30 to 35 (1.181 to 1.378)
Track adjustment
Force (9) kg (lbf) 7.3 (16)
GSX/MX Z (Adrenaline) SC 3 121 in
GTX SC 3 136 in
MX Z (Renegade/Renegade X) SC 3 136 in
Tra ck
MX Z (X) SC 4
Suspension type
Ski R.A.S. A-arm
BRAKE
Brake fluid reservoir mL (U.S. oz) 60 (2.0)
GTLMA (DOT 4) (P/N 293 600 062)
Brake fluid (P/N)
Racing brake fluid SRF (DOT 4) (P/N
293 600 063)
