Section 03 ENGINES
Subsection 03 (ENGINE REMOVAL AND INSTALLATION)
A33C4MA
1
1. Knock sensor connector
Detach upper thermostat hose from thermostat
housing.
A33C2EA
1
1. Remove this hose
Disconnect temperature sensor connectors.
A33C2FA
Remove spark plugs and install the spark plug lift
ring (P/N 529 035 830) at the farthest spark plug
hole.
1
A33C18A
1. Spark plug lift ring
Remove RAVE valves.
Unscrew engine support bolts no. 1.
68 mmr2005-070
