8630 - 135
DEVICENET
Safety settings on bus failure
The actuator moves to the position corresponding to the setpoint last transmitted (default setting).
For other setting options (see the chapter Settings on the TOP Control Continuous)
Drop line length (Drop Lines)
Technical data
EDS file BUER8630.EDS
Icons BUER8630.ICO
Baud rate 125 kBit/s, 250 kBit/s, 500 kBit/s (adjustable via keys at the device or via
network);
Factory setting 125 kBit/s
Adress 0 ... 63; (adjustable via keys at the device or via network);
Factory setting 63
Process data 7 static Input Assemblies
(Input: from TOP Control Continuous to DeviceNet Master/Scanner)
4 static Output Assemblies
Total line length according to DeviceNet specification
(Total line length = sum of all mein and drop lines)
Baud rate
Maximum total line length
Thick Cable Thin Cable
125 kBaud 500 m
100 m for all baud rates250 kBaud 250 m
500 kBaud 100 m
Baud rate Length of drop lines
Maximum length Maximum total length of drop lines in network
125 kBaud 6 m for all baud rates 156 m
250 kBaud 78 m
500 kBaud 39 m
