8630 - 27
SYSTEM DESCRIPTION
* Interfaces of the TOP Control Continuous
in the multipole variant
Inputs for position or
process setpoint
4..20 mA
0..20 mA
0..10 V
0..5 V
Input for process setpoint
4..20 mA
Frequency
Pt 100
* Flow rate controller
Binary input
24 V DC
Sup-
ply
Inputs
Outputs
Operating unit
TOP Control
Continuous
(multipole - variant)
2 binary outputs
*Initiators 1 + 2
Analog position feedback
NOTE
TOP Control Continuous Type 8630 is a 3-conductor device, i.e. the voltage supply (24 V
DC) is separate from the setpoint signal.
* Note:
Inputs for process value with flow rate controller (option): p
1
,
p
2
, T (optional).
The standard process controller inputs (4 ... 20 mA, frequency, Pt 100) and the initiators cannot be used with this option.
