34 - 8630
FIRST COMMISSIONING
Fluidic installation
➔ Install the valve according to operating
instructions!
➔ Connect supply pressure to connection "1" (3
.. 7 bar; instrument air, free from oil, water
and dust)
➔ Attach the exhaust line or silencer to
connection "3"!
NOTE
This section enable you to put the TOP Control
Continuous
rapidly into operation for a
functional check. Supplementary functions unnecessary for this purpose are not dealt with
here.
Remove the protective caps from the valve and and the TOP Control
Continuous!
NOTE
