Burkert 8630 - Commissioning and Set-Up as a Positioner; Procedure for Specifying the Basic Settings

8630 - 53
OPERATION AND CONTROLLER FUNCTIONS
Configuration of the keys
MANUAL/AUTOMATIC-key Switch between main and sub-menu items, e.g.
ACT FUNC - FUNCSNGL
Arrow keys Switch between eual-ranking menu items, e.g.
ACTFUNC - INPUT
Commissioning and set-up as a positioner
➔ Before commissioning, execute the fluidic and electrical installations.
Procedure for specifying the basic settings
➔ On first commissioning of the TOP Control Continuous, carry out the following basic settings:
• Specify the function of the pneumatic actuator used.
• Specify the standard signal input for setpoint setting (4..20 mA, 0..20 mA, 0..10 V or 0..5 V).
• Start the automatic adaptation of the positioner to the current operating conditions (AUTOTUNE).
Factory setting of the positioner
Function Factory setting
ACTFUNC FUNCSNGL
INPUT INP 4'20A
CHARACT CHA LIN
DIR.CMD DIR.CRISE
CUTOFF CUT = 0 %; CUT = 100 %
DIR.ACT DIR.ARISE
SPLTRNG SR = 0 (%); SR = 100 (%)
X.LIMIT LIM = 0%, LIM = 100%
X.TIME
T.OPN Values determined by AUTOTUNE
T.CLS Values determined by AUTOTUNE
After execution of SETFACT: 1 s
Function Factory setting
OUTPUT
OUT ANL:
OUT POS OUT 4
' 20 A
OUT BIN:
OUT DEV DEV 5.0 NO
BIN-IN
B.IN SPOS SPOS 000 NO
X.CONTROL
X.CO DBND
1 %
X.CO PARA
KX
Values determined by AUTOTUNE
KX Values determined by AUTOTUNE
After execution of SETFACT: 1
CODE CODE 0000
