Static Output Assemblies
The addresses given in the table Static Output Assemblies can be used as path statement for the
attribute Consumed Connection Path of an I/O connection, whereby the attributes described in more
detail in the following table can be transferred as Output Process Data via this I/O connection.
Independently from this however, it is also possible to acyclically access the attributes combined in the
Assemblies via Explicit Messages .
Name Address Data Attribute of the assemblies for
Write/Read access Class, Instance, Attribute
Format of the Data
Attribute
INP (factory setting) 4, 21, 3 Byte 0: INP low
Byte 1: INP high
SP 4, 22, 3 Byte 0: SP low
Byte 1: SP high
MTMP 4, 23, 3 Byte 0: MTMP low
Byte 1: MTMP high
SP+MTMP 4, 24, 3 Byte 0: SP low
Byte 1: SP high
Byte 2: MTMP low
Byte 3: MTMP high
Name Description of the Output Data Attributes Attribute address,
Class, Instance,
Attribute; data type,
length
INP Position setpoint
Setpoint of position controller in ‰.
Value range 0...1000.
In "purely" position controller operation (PCONTRL
inactiv) transmission of the setpoint position INP is
necessary; as process controller (PCONTRL activ)
the transmission of INP is not possible. In the case of
too small or too large a value, the last valid is used
and indicated in ERR with HEX 14.
111, 1, 58;
UINT, 2 Byte
SP Process-set-value (Process Setpoint)
Set-value process controller in physical unit (as set up
in the P.CO INP or P.CO SCAL menu), max. value
range –999...9999, depending on the internal scaling.
If the value is too small or too large, the last valid
value will be used and will be displayed in ERR with
HEX 15.
120, 1, 2;
INT, 2 Byte
MTMP Medium temperature
Temperature of the medium in °C.
Value range -20 ... 150.
If the value is too small or too large, the last valid
value will be used and will be displayed in ERR with
HEX 18.
120, 1, 9;
INT, 2 Byte
