SYSTEM DESCRIPTION
Factory settings on the TOP Control Continuous
Function Factory setting
ACTFUNC FUNCSNGL
INPUT INP 4'20 A
CHARACT CHA LIN
DIR.CMD DIR.CRISE
CUTOFF CUT
0 %, CUT 100 %
DIR.ACT DIR.ARISE
SPLTRNG SR 0 (%), SR 100 (%)
X.LIMIT LIM 0 %, LIM 100 %
X.TIME
T.OPN Values calculated by AUTOTUNE
T.CLS Values calculated by AUTOTUNE
After execution of SETFACT : 1 s
OUTPUT
OUT ANL:
OUT POS OUT 4´20 A
OUT BIN:
OUT DEV DEV 5.0 NO
BIN-IN
B.IN SPOS SPOS 000 NO
Function Factory setting
X.CONTRL
X.CO DBND 1 %
X.CO PARA
KX
Values calculated by AUTOTUNE
KX Values calculated by AUTOTUNE
After execution of SETFACT : 1
P.CONTRL
P.CO DBND 1 %
P.CO PARA
KP 1.00
TN 999.9
TV 0.0
X0 0
P.CO SETP SETP INT
P.CO INP INP 4´20 A
P.CO FILT 0
P.CO SCAL PV 000.0, PV 100.0
P.CO TUNE D’ACT
P.CO KV FACT
P.CONTRL with flow rate controller
P.CO DBND 1 %
P.CO PARA
KP 1.0
TN 999.9
TV 0.0
X0 0
P.CO SETP SETP INT
P.CO INP INP P1’P2
P.CO FILT 0
P.CO SCAL PV 000.0, PV 100.0
P.TYP FLOW
UNIT M3/H
TEMP MAN
DENS 1.293
DIAM 0025
P.CO TUNE D’ACT
P.CO KV FACT
CODE CODE 0000
NOTE
The functions and factory settings shown in grey are valid for the optional
flow rate control.
