Cambium Networks Force 4600C User Manual

Chapter 2: System Hardware
124
Force 300 CSML interfaces
The Ethernet port is located on the rear of the connectorized unit.
Figure 54: Rear interfaces
Table 92 Force 300 CSML Series – Rear interfaces
Port name
Connector
Interface
Description
Ethernet
RJ45
24V PoE input
10/100BASE-T
100 BASE-TX
Ethernet
Management and data
Reset
Button
Physical
button
N/A
For resetting the radio and for setting the radio back to its
factory default configuration.
Force 300 CSML mounting bracket
The Force 300 CSML module is designed to be pole-mounted using the mounting bracket provided in
the box with the radio.
An overview of Force 300 CSML mounting bracket is shown in Figure 55.
