Chapter 4: Using the Device Management Interface
Using the installation wizard – Access Point
The ePMP device provides a guided configuration mechanism for configuring key parameters for the link
operation.
This setup can be accessed from the
Installation
page by clicking the
button.
Click
Finish Setup
to commit the changes to the device.
Step 1: Main system parameters
Figure 69:
Quick Start page
The configured identifier used in an NMS such as cnMaestro
Enabled
: 802.11n ePMP subscribers can register to the AP (requires subscriber
software upgrade).
Disabled
: 802.11n ePMP subscribers are not able to register to the AP.
SSID is a unique identifier for a wireless LAN which is specified in the AP’s beacon.
(Access Point Mode). SSID must be the same at both ends and different from the site
name.
