Chapter 2: System Hardware
Table 38 Force 300-25L – rear interfaces
Power over Ethernet (PoE).
Force 300-25L specifications
The Force 300-25L integrated module conforms to the specifications listed in Table 39 and Table 40. The
integrated module meets the low-level static discharge specifications identified in Electromagnetic
compatibility (EMC) compliance and provides internal surge suppression, but does not provide lightning
suppression.
Table 39 Force 300-25L physical specifications
Dimensions (Diameter x Depth)
TBDmm x TBDmm x TBDmm (TBDin x TBDin x TBDin)
3.8 cm
–
6.4 cm (1.5 in
–
2.5
in)
12 W Maximum, 9 W Typical
30 V Passive PoE (14-30V DC input)
Table 40 Force 300-25L environmental specifications
-30°C to +55°C (-22°F to +122°F) ambient op temp
200 km/hour (124 mi/hour)
IP55
Note
This product meets the UL/cUL 62368 / IEC 62368 edition 2
specification, and the radio housings are designed to be rain-tight.
Force 300-25L heater
At start-up, if the Force 300-25L module temperature is at or below 32°F (0°C), an internal heater is
activated to ensure that the device can successfully begin operation. The unit’s heater is only activated
when the unit is powered on and will not apply heat to the device once the startup is complete. When the
unit temperature is greater than 32°F (0°C), the heater is deactivated, and the unit continues its start-up
sequence.
The effect on device startup time at various temperatures is defined in Table 41.
