ePMP 4500C Access Point mounting bracket
The ePMP 4500C AP module is designed to be mounted with a external antenna or pole-mounted using
the mounting bracket provided in the box with the radio.
An overview of ePMP 4500C AP mounting bracket is shown in Figure 33
Figure 33:
ePMP 4500C Access Point module mounting bracket
ePMP 4500C Access Point interfaces
The Ethernet port is located at the bottom of the unit. This interface is described in Table 22.
Table 22 ePMP 4500C Series– rear interfaces
Power over Ethernet (PoE).
Note
All RJ45 Ethernet LAN cables used for
providing power or are connected to
power ports (PoE) must be UL
certified with VW-1 markings.
