Figure 6:
ePMP 4600
A summary of the main ePMP 4600 characteristics are listed under Table 2.
Table 2 Main characteristics of theePMP 4600 Series
20 MHz, 40 MHz, 80 MHz, 160 MHz
ePMP 4500L
The ePMP 4500L is the third-generation Access Point (AP) that carries on the interference tolerance
mechanisms with an emphasis on high-performance in low-density point to multipoint sectors. The ePMP
4500L is a 2 x 2 MIMO connectorized AP that can support a wide variety of deployments including
90/120-degree sectors, narrow-sector horns, or even 360-degree Omni coverage.
The ePMP 4500L system consists of the ePMP 4500L AP, an optional 2x2 sector antenna, and a wide
variety of subscriber modules with varying form factors and link budgets.
The ePMP 4500L system boasts a high packet per second performance, peak throughput of
1
Gbps, and
supports subscriber modules with up to
1
Gbps of peak throughput.
An over view of ePMP 4500L is shown in Figure 7
