Chapter 2: System Hardware
ePMP Force 300-25-25 5 GHz High Gain Radio (RoW) (ANZ Cord)
ePMP Force 300-25-25 5 GHz High Gain Radio (RoW) (South Africa Cord)
ePMP Force 300-25-25 5 GHz High Gain Radio (RoW) (No PSU)
Table 29 Force 300-25 accessory part numbers
PoE Gigabit DC Injector, 15W Output at 30V, Energy Level 6 Supply
CABLE, UL POWER SUPPLY CORD SET, ARGENTINA
CABLE, UL POWER SUPPLY CORD SET, AUS/NZ
CABLE, UL POWER SUPPLY CORD SET, Brazil
CABLE, UL POWER SUPPLY CORD SET, CHINA
CABLE, UL POWER SUPPLY CORD SET, EU
CABLE, UL POWER SUPPLY CORD SET, INDIA
CABLE, UL POWER SUPPLY CORD SET, UK
CABLE, UL POWER SUPPLY CORD SET, US
Force 300-25 mounting bracket
The Force 300-25 module is designed to be pole-mounted using the mounting bracket provided in the
box with the radio.
An overview of Force 300-25 mounting bracket is shown in Figure 42.
Figure 42:
Force 300-25 module mounting bracket
Force 300-25 interfaces
The Ethernet port is located on the rear of the integrated unit. This interface is described in Table 30.
