Cambium Networks Force 4600C User Manual

Chapter 1: Product Description
31
Figure 10: Force 300-19
A summary of the main Force 300-19 characteristics are listed under Table 4.
Table 4 Main characteristics of the Force 300-19 Series
Characteristic
Value
Topology
PMP, PTP
Wireless link condition
LoS, near LoS
Scheduler
TDD
Connectivity
Ethernet
Operating frequencies
Unlicensed bands, 5 GHz
Channel Bandwidth
20 MHz, 40 MHz, 80 MHz
Data rate
Up to 500+ Mbps
Force 300-19R
The Force 300-19R is a rugged high-capacity outdoor point-to-multipoint or point-to-point link wireless
device in the unlicensed 5 GHz frequency bands with a maximum UDP throughput of 600+ Mbps (when
operating with 80 MHz channel bandwidth). The Force 300-19R is IP67 rated capable of operating in line-
of-sight (LoS) and near-LoS conditions. Force 300-19R is available as an integrated unit with a dual-
polarized 19dBi integrated flat-panel antenna.
Force 300-19R is based on highly integrated wireless semiconductor components designed to meet the
IEEE 802.11ac standard, however, the Force 300-19R device has a proprietary air interface for the main
point-to-point link.
Force 300-19R is powered by standard power-over-Ethernet to a 1000BASE-T port.
Management of the unit is conducted via the same interface as the bridged traffic (in-band Management).
An over view of Force 300-19R is shown in Figure 11
