Chapter 2: System Hardware
Figure 55:
Force 300 CSML module mounting bracket
Force 300 CSML specifications
The Force 300 CSML module conforms to the specifications listed in Table 93 and Table 94. The
connectorized module meets the low-level static discharge specifications identified in Electromagnetic
compatibility (EMC) compliance and provides internal surge suppression but does not provide lightning
suppression.
Table 93 Force 300 CSML physical specifications
Dimensions (Diameter x Depth)
0.521 kg (1.15 lbs) without antenna
Table 94 Force 300 CSML environmental specifications
-30°C to +55°C (-22°F to +122°F)
IP55
Note
This product meets the UL/cUL 62368 / IEC 62368 edition 2
specification, and the radio housings are designed to be rain-tight.
Force 300 CSML wind loading
Ensure that the device and the structure on which it is mounted are capable of withstanding the
prevalent wind speeds at a proposed ePMP site. Wind speed statistics are available from national
meteorological offices.
The device and its mounting brackets are capable of withstanding wind speeds of up to 125 kph
(78 mph).
Wind blowing on the device will subject the mounting structure to significant lateral force. The
magnitude of the force depends on both wind strength and surface area.
