Force 300-16
The Force 300-16 is a rugged high-capacity outdoor point-to-multipoint or point-to-point link wireless
device in the unlicensed 5 GHz frequency bands with a maximum UDP throughput of 500+ Mbps (when
operating with 80 MHz channel bandwidth). It is capable of operating in line-of-sight (LoS) and near-LoS
conditions. Force 300-16 is available as an integrated unit with a dual-polarized 16 dBi integrated
antenna.
Force 300-16 is based on highly integrated wireless semiconductor components designed to meet the
IEEE 802.11ac standard, however, the Force 300-16 device has a proprietary air interface for the main
point-to-point link.
Force 300-16 is powered by standard power-over-Ethernet to a 1000BASE-T port.
Management of the unit is conducted via the same interface as the bridged traffic (in-band Management).
An over view of Force 300-16 is shown in Figure 12.
Figure 12:
Force 300-16
A summary of the main Force 300-16 characteristics is listed under Table 6 .
Table 6 Main characteristics of the Force 300-16 Series
