Force 300-13
The Force 300-13 is a rugged high-capacity outdoor Point-to-Multipoint or Point-to-Point link wireless
device in the unlicensed 5 GHz frequency bands with a maximum UDP throughput of 500+ Mbps (when
operating with 80 MHz channel bandwidth). It can operate in line-of-sight (LoS). Force 300-13 is available
as an integrated unit with a dual-polarized 13 dBi flat-panel antenna.
Force 300-13 is based on highly integrated wireless semiconductor components designed to meet the
IEEE 802.11ac standard, however, the Force 300-13 device has a proprietary air interface for the main
point-to-point link.
Force 300-13 is powered by standard power-over-Ethernet to a 1000BASE-T port.
Management of the unit is conducted via the same interface as the bridged traffic (in-band Management).
An over view of Force 300-13 is shown in Figure 13
Figure 13:
Force 300-13
A summary of the main Force 300-13 characteristics are listed under Table 7.
Table 7 Main characteristics of the Force 300-13 Series
