Cambium Networks Force 4600C User Manual

Chapter 1: Product Description
35
Force 300-13L
The Force 300-13L is an affordable subscriber module in the ePMP Force 300 series. The Force 300-13L
uses 802.11ac technology and supports MU-MIMO and other features offered by the ePMP 3000 and
ePMP 3000L APs. It is also backward compatible with the ePMP 2000 using backward compatibility
features. The Force 300-13L is powered by standard power-over-Ethernet to a 1000BASE-T port. An
over view of Force 300-13L is shown in Figure 14
Figure 14: Force 300-13L
A summary of the main Force 300-13L characteristics is listed under Table 8.
Table 8 Main characteristics of the Force 300-13L Series
Characteristic
Value
Topology
PMP, PTP
Wireless link condition
LoS
Scheduler
TDD
Connectivity
Ethernet
Operating frequencies
Unlicensed bands, 5 GHz
Channel Bandwidth
20 MHz, 40 MHz, 80 MHz
Data rate
Up to 400+ Mbps
Force 300 CSM
The Force 300 CSM is an IP67 rugged high-capacity outdoor point-to-multipoint or point-to-point link
wireless device in the unlicensed 5 GHz frequency bands with a maximum UDP throughput of 600+ Mbps
(when operating with 80 MHz channel bandwidth). It can operate in line-of-sight (LoS). Force 300 CMS is
