Cambium Networks Force 4600C User Manual

Chapter 1: Product Description
36
a Connectorized device with support for RF Element Twistport™ adaptors.
The Force 300 CSM device is based on highly integrated wireless semiconductor components designed
to meet the IEEE 802.11ac standard.
Management of the unit is conducted via the same interface as the bridged traffic (in-band Management).
An over view of Force 300 CSM is shown in Figure 15.
Figure 15: Force 300 CSM
A summary of the main Force 300 CSM characteristics are listed under Table 10 .
Table 10 Main characteristics of the Force 300 CSM
Characteristic
Value
Topology
PMP, PTP
Wireless link condition
LoS
Scheduler
TDD
Connectivity
Ethernet
Operating frequencies
Unlicensed bands, 5 GHz
Channel Bandwidth
20 MHz, 40 MHz, 80 MHz
Data rate
Up to 600+ Mbps

Cambium Networks Force 4600C Specifications

General

Brand	Cambium Networks
Model	Force 4600C
Category	Network Hardware
Language	English
