Chapter 2: System Hardware
Table 30 Force 300-25 Series – rear interfaces
Power over Ethernet (PoE).
Note
All RJ45 Ethernet LAN cables used for
providing power or are connected to
power ports (PoE) must be UL certified
with VW-1 markings.
Force 300-25 specifications
The Force 300-25 integrated module conforms to the specifications listed in Table 31 and Table 32.
The integrated module meets the low-level static discharge specifications identified in Electromagnetic
compatibility (EMC) compliance and provides internal surge suppression but does not provide lightning
suppression.
Table 31 Force 300-25 physical specifications
Dimensions (Diameter x Depth)
47 cm x 31 cm (18.5 in x 12.2 in)
Table 32 Force 300-25 environmental specifications
-30°C (-22°F) to +55°C (131°F)
124 mph (200 kph) maximum. See Force 300-25 wind loading for a full description.
IP55
Note
This product meets the UL/cUL 62368 / IEC 62368 edition 2
specification, and the radio housings are designed to be rain-tight.
Force 300-25 heater
At startup, if the Force 300-25 module temperature is at or below 32°F (0°C), an internal heater is
activated to ensure that the device can successfully begin operation. The unit’s heater is only activated
when the unit is powered on and will not apply heat to the device once the startup is complete. When the
unit temperature is greater than 32°F (0°C), the heater is deactivated, and the unit continues its startup
sequence.
