Chapter 2: System Hardware
ePMP 4600 6 GHz 4x4 Access Point Radio (ROW) (UK cord)
ePMP 4600 6 GHz 4x4 Access Point Radio (EU) (UK cord)
ePMP 4600 6 GHz 4x4 Access Point Radio (ROW) (India cord)
ePMP 4600 6 GHz 4x4 Access Point Radio (India) (India Cord)
ePMP 4600 6 GHz 4x4 Access Point Radio (ROW) (China cord)
ePMP 4600 6 GHz 4x4 Access Point Radio (ROW) (Brazil cord)
ePMP 4600 6 GHz 4x4 Access Point Radio (ROW) (Argentina cord)
ePMP 4600 6 GHz 4x4 Access Point Radio (ROW) (ANZ cord)
ePMP 4600 6 GHz 4x4 Access Point Radio (ROW) (South Africa cord)
ePMP 4600 6 GHz 4x4 Access Point Radio (ROW) (No PSU)
ePMP 4600 6 GHz 4x4 Access Point Radio (FCC) (US cord)
ePMP 4600 6 GHz 4x4 Access Point Radio (Indonesia) (EU Cord)
ePMP 4600 Access Point mounting bracket
The ePMP 4600 AP module is designed to be mounted with a sector antenna or pole-mounted using the
mounting bracket provided in the box with the radio.
An overview of ePMP 4600 AP mounting bracket is shown in Figure 37
Figure 37:
ePMP 4600 Access Point module mounting bracket
ePMP 4600 Access Point interfaces
The Ethernet port is located at the bottom of the unit. This interface is described in Table 22.
