Operation Panel
A: ON button
Turns the power on or off. Before turning on the power, make sure that the document cover is closed.
Turning the Printer On and Off
B: HOME button
Used to display the HOME screen.
Using Touch Screen
C: Back button
Returns to the previous screen.
D: Status light
Lights when the power is turned on.
E: Touch Screen
Displays messages, menu items, and operating status. Touch the screen lightly with your finger to
select a menu item or button.
Using Touch Screen
F: Stop button
Cancels operation when print, copy, scan, or fax transmission/reception job is in progress.
G: Black button
Starts black & white copying, scanning, faxing, etc.
H: Color button
Starts color copying, scanning, faxing, etc.
I: FAX Memory lamp
Lights when there are received or unsent documents stored in the printer's memory.
50
