Rear View
A: Transport Unit
Open when removing jammed paper. When removing the unit, do so after placing a finger on the
depression in the center right.
B: Rear Cover
Detach when removing jammed paper.
C: Power Cord Connector
Plug in the supplied power cord.
D: External Device Jack
Connect an external device such as telephone or answering device.
E: Telephone Line Jack
Connect the telephone line.
F: USB Port
Plug in the USB cable to connect the printer with a computer.
G: Wired LAN Connector
Plug in the LAN cable to connect the printer to a LAN.
Important
• Do not touch the metal casing.•
• Do not plug in or unplug the USB cable while the printer is printing or scanning with the computer. This•
can cause trouble.
48
