Loading Based on Use
Load the original in the correct position according to the function to use. If you do not load the original
correctly, it may not be scanned properly.
Originals Function How to Load
Magazines, Newspapers, and
Documents
Copying or Faxing Loading the Original to Be Aligned
with the alignment mark
Scanning by specifying a standard
size
If you scan using the operation panel,
select Document or Photo for Doc.type
in Scan and specify a standard size for
Scan size to scan originals.
Photos and Postcards Scanning only one original
If you scan using the operation panel, fol-
low the operation below.
• Select Photo for Doc.type in Scan•
and specify Auto scan for Scan size
to scan originals.
Loading Only One Original in Cen-
ter of Platen
Scanning two or more originals
If you scan using the operation panel, fol-
low the operation below.
• Select Photo for Doc.type in Scan•
and specify Auto multi scan for
Scan size to scan two or more origi-
nals.
Loading Two or More Originals on
Platen
Loading the Original to Be Aligned with the alignment mark
Place the original WITH THE SIDE TO SCAN FACING DOWN on the platen and align it with the
alignment mark . Portions placed on the diagonally striped area cannot be scanned.
Important
• The printer cannot scan the striped area (A) (0.04 in. (1 mm) from the edges of the platen glass).•
84
