Carel WB000DG0F0 User Manual

12
ENG
UltraCella +0300083EN - rel. 1.5 - 07.02.2015
2.4 Expansion modules assembly
Dimensions (mm)
260
drilling template
47,5
47,5
30
128 110
290
87,5
107,5
Ø32
103
Ø 4,5
47,5
47,5
30
101
87,5
107,5
Ø32
Fig. 2.f
Overall drilling template (mm)
If UltraCella and expansion modules have to be mounted at the same
time, use the overall drilling template.
260
103
Ø 4,5 mm
156
24
DIN RAIL
UltraCella
Expansion
Module
3343214
Fig. 2.g
Layout
If more than one expansion modules it is to assemble, use the
arrangement of fi gure to optimize the wiring.
1
2
1
2
UltraCella Control
Power Module
EVD Module
Fig. 2.h
Mounting
A B
1
2
1
2
3
1
2
1
2
3
2
2
1
2
1
2
1
1
1: Use a hole saw to drill the panel in correspondence with the predrilled
holes (steps A, B). If present, fasten the DIN rail for the module
.
2: Remove the faceplates. Unscrew the screws (3) and open the
UltraCella control
WM00ENS000
WM00ENSI00
WM00ENNI00
