UltraCella +0300083EN - rel. 1.5 - 07.02.2015
6.15 Humidity management
UltraCella can interact with CAREL humidifi cation systems, managing the
humidity level in combination with cooling control.
The humidity must be read from UltraCella, confi guring an analogue
input (B4 or B5) as a 0 to 10 V or 4 to 20 mA input for humidity probes.
The controller can display the humidity read by the probe and, by suitably
confi guring one of the auxiliary outputs, AUX1 or AUX2, activate an
external CAREL humidifi er to adjust the humidity level accordingly.
Carel Humidifi cation systems are compatible with UltraCella
humiSonic mc multizone humiDisk
Fig. 6.y
Wiring diagram between UltraCella and humiSonic
FieldBus
24 Vac
BMS
R6
R5
R4
R3
R2
R1
230 V
20 A max
EN60730-1
UL 873
250 V
R5 - R6
12 (10) A
12 A res. 2HP
12FLA 72 LRA
CAREL NTC, PT1000
CAREL NTC, PT1000
CAREL NTC, PT1000
CAREL NTC, analog input 0 to 10 Vdc
B5 analog input
(4 to 20 mA)
OUT
M
+V
0 to 5 Vdc
DI1
(**)
Door switch
B3
B2
B1
48 47 46 45 44 43
49 50 51 52 53 54
VL
GND GND
Rx/Tx+
Rx/Tx-
GND
Rx/Tx+ Rx/Tx- GND Rx/Tx+ Rx/Tx- GND
Y1
B4
B5
DI1
DI2
DI3
GND
5 VREF
+ Vdc
30
29
28
31
42
27
26
25
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
24
23
22
analog output (0 to 10 Vdc)
EN60730-1
UL 873
250 V
R3 - R4
10 A res.
5 (3) A
10 A res. 5FLA
18 LRA
EN60730-1
UL 873
250 V
R1 - R2
8 (4) A N.O.
8 A res. 2FLA
12 LRA
DEF
GND Tx Rx ON/OFF
(4)
(1) RS485
Supervisione
Supervision
FAN
LIGHT
UltraCella Control
humiSonic
Fig. 6.z
Connection between UltraCella and humiSonic
