Carel WB000DG0F0 User Manual

53
ENG
UltraCella +0300083EN - rel. 1.5 - 07.02.2015
7. PARAMETERS TABLE
Par. Description Def Min Max UOM Type CAREL SVP Modbus
SVP
R/W page
Pro
/21 Probe measurement stability probe 1 4 0 9 - I 12 51 R/W 37
/22 Probe measurement stability probe 2 4 0 9 - I 13 52 R/W 37
/23 Probe measurement stability probe 3 4 0 9 - I 14 53 R/W 37
/24 Probe measurement stability probe 4 4 0 9 - I 15 54 R/W 37
/25 Probe measurement stability probe 5 4 0 9 - I 16 55 R/W 37
/4 Virtual probe composition
0 = probe B1
100= probe B2
0 0 100 - I 17 56 R/W 43
/5t Temperature unit of measure
0/1 = °C for temperature and Bar for pressure sensors / °F for temperature
and psi for pressure sensors of EVD (if present)
0 0 1 - I 18 57 R/W 38
/6 Display decimal point
0/1 = yes/no
0 0 1 - D 19 8 R/W 38
/t1 Display variable 1
0 None 6 B1
1 Virtual probe (Sv) 7 B2
2 Outlet probe (Sm) 8 B3
3 Intake probe (Sr) 9 B4
4 Defrost probe 1 (Sd1) 10 B5
5 Defrost probe 2 (Sd2) 11 Sc
6 Set point
1 0 12 - I 67 106 R/W 37
52
/t2 Display variable 2 (*)
0 None. 10 B4
1 Virtual probe (Sv) 11 B5
2 Outlet probe (Sm) 12 rd
3 Intake probe (Sr) 13 Superheat
4 Defrost probe 1 (Sd1) 14 Valve opening %
5 Defrost probe 2 (Sd2) 15 Valve opening step
6 Set point 16 Sc
7 B1 17 Sd1 (3PH mod.)
8 B2 18 Sd2 (3PH mod.)
9 B3 19 Sc (3PH mod.)
6 0 19 - I 68 107 R/W 37
52
/P Type B1 to B3
0 NTC Standard range -50T90°C
1 NTC extended range 0T150°C
2 PT1000
0 0 2 - I 20 59 R/W 34
/A2 B2 confi guration
0 Absent
1 Defrost probe 1 (Sd1)
2 Intake probe (Sr)
0 0 2 - I 21 60 R/W 34
/A3 B3 confi guration
0 Absent
1 Defrost probe 2 (Sd2)
2 Condenser probe (Sc)
3 Defrost probe 1 (Sd1)
0 0 3 - I 22 61 R/W 34
/P4 Type B4
0 NTC Standard range -50T90°C
1 NTC Extended range 0T150°C
2 0…10 V
0 0 2 - I 23 62 R/W 34
52
/A4 B4 confi guration
0 Absent
1 Ambient temperature probe
2 Humidity probe
0 0 2 - I 24 63 R/W 34
52
/P5 Type B5
0 4 … 20 mA
0 0 0 - I 25 64 R/W 34
52
/A5 B5 confi guration
0 Absent
1 Humidity probe
0 0 1 - I 26 65 R/W 34
52
/C1 Off set B1 0 -20.0 20.0 °C/°F A 7 0 R/W 34
/C2 Off set B2 0 -20.0 20.0 °C/°F A 8 1 R/W 34
/C3 Off set B3 0 -20.0 20.0 °C/°F A 9 2 R/W 34
/C4 Off set B4 0 -20.0 20.0 - A 10 3 R/W 34
/C5 Off set B5 0 -20.0 20.0 - A 11 4 R/W 34
St Set point 0 r1 r2 °C/°F A 12 5 R/W 43
rd Diff erential 2.0 0.1 20 °C/°F A 13 6 R/W 43
r1 Minimum set point -50.0 -50.0 r2 °C/°F A 14 7 R/W 43
r2 Maximum set point 60.0 r1 200 °C/°F A 15 8 R/W 43
r3 Operating mode
0 direct with defrost
1 direct without defrost
0 0 1 - D 11 0 R/W 43
StH Humidity setpoint 90.0 0.0 100.0 %rH A 28 19 R/W 52
rdH Humidity diff erential 5.0 0.1 20.0 %rH A 29 20 R/W 52
(*): can be viewed only on UltraCella Sevice Terminal or on the controller with double row display.
Type of variable: A = analogue, I = integer, D = digital
