9.5 3pH FULL Modules technical characteristics
Power supply voltage: 400V~(+10/-15%), 50/60Hz, 3PH+N+T, Imax 25A
Classifi cation according to protection against electric shock Class I
Case plastic, dimensions 452x380x186 mm
Weight 9,8 Kg
Front protection rating with plastic case IP65
Cleaning the module front panel only use neutral detergents and water
Operating conditions -10T40°C, <90% r.H. non condensing
Storage conditions -20T60°C, <90% r.H. non condensing
Materials frontal cover in polycarbonate, retro box in technopolymer
Tab. 9.f
9.5.1 Electrical characteristics
Ultra 3PH Full module 4HP Ultra 3PH Full module 7,5HP
Code WT00F4B0N0 WT00F7C0N0
General
Main switch / general protection 4 poles magnetothermic 16A 6kA D 4 poles magnetothermic 25A 6KA D
Loads power supply
400V~ (±10%), 50/60Hz, 3PH+N+T 400V~ (±10%), 50/60Hz, 3PH+N+T
Insulating transformer PRI 230 Vac
SEC1 230 Vac 40VA
SEC2 24 Vac 35VA
Protection SEC by fuses
PRI 230 Vac
SEC1 230 Vac 40VA
SEC2 24 Vac 35VA
Protection SEC by fuses
Status and alarm indication By UltraCella By UltraCella
Regulation range of compressor current rating 10…16A (AC3) 3PH 16…20A (AC3) 3PH
Input
Main defrost probe NTC 10kΩ NTC 10kΩ
Auxiliary evap. defrost probe NTC 10kΩ NTC 10kΩ
Condensing probe NTC 10kΩ NTC 10kΩ
Partial condenser Present Present
Pump down Present Present
High/Low pressure Present Present
Kriwan compressor Present Present
Clicson evaporator Present Present
Thermostat evaporator Present Present
Output
Compressor 10...16A (AC3) 3PH 16...20A (AC3) 3PH
Oil compressor heater (Carter) 100W, 0,5A (AC1) 1PH 100W, 0,5A (AC1) 1PH
Condensing fans 0,8kW, 4A (AC15) 1PH 0,8kW, 4A (AC15) 1PH
Defrost heaters 6kW, 9A (AC1) 3PH 9kW, 13A (AC1) 3PH
Evaporator fans 0,55kW, 1,5A* (AC23) 3PH
0…10Vdc
2kW, 5,7A* (AC23) 3PH
0…10Vdc
AUX1 output 16A (AC1) 1PH 16A (AC1) 1PH
Solenoid valve Present Present
Tab. 9.g
* Rating with cosφ=0,5;
With diff erent power factor, to calculate the rating consider the formula: I = P / (400 * √3 * cosφ) where P is the power in W
